Supported Microcontrollers（For Multi RAM data monitor (measurement) tool ）
The following are supported with microcontrollers for MCU probes(GT10□△△△（□:2/6）) and Automotive probe(GT10□△△△（□：3/4/7）) products.
| Semiconductor Supplier |
Microcontroller Series/Family Name |
Representative Microcontroller Model Name： Debug-I/F（Microcontroller name） |
Probe Type Name：GT10□△△△ | |||||
|---|---|---|---|---|---|---|---|---|
| △△△ MCU type |
GT102 | GT103 | GT104 | GT106 | GT107 | |||
| Renesas Electronics |
SH2/SH2A Series |
Debug-I/F:AUD(Sh705x) Debug-I/F:AUDⅡ(sh725x) |
H02 | ◯ | ◯ | ◯ | ||
| SH7450 Series |
Debug-I/F:AUDR(SH'745x) | H03 | ◯ | ◯ | ◯ | |||
| SH7253 Series |
Debug-I/F:HUDI(SH72531) | H04 | ◯ | ◯ | ◯ | |||
| M32R Family |
Debug-I/F:RTD(M32R/ECU) | L01 | ◯ | ◯ | ||||
| Debug-I/F:NBD(M32R/ECU) | L02 | ◯ | ◯ | ◯ | ||||
| Debug-I/F:SDI(M32R/ECU) | L03 | ◯ | ||||||
| V850E1 Family |
Debug-I/F:NBD (V850/IA1,V850/PG2) |
N01 | ◯ | ◯ | ◯ | |||
| V850E2 Family |
Debug-I/F:NEXUS (V850E2/Px4,V850E2/Fx4) |
N04 | ◯ | ◯ | ◯ | |||
| RH850 Family |
Debug-I/F:NEXUS (RH850/E1x,RH850/F1x, RH850/p1x,RH850/c1x) |
H06 | ◯ | ◯ | ◯ | |||
| RL78 Family |
Debug-I/F:LPD (RL78/F13,F14,F15) |
H07 | ◯ | |||||
| RX Family |
Debug-I/F:JTAG (RX600,RX700 Series RX660,RX26T Group) |
H08 | ◯ | ◯ | ◯ | |||
| RH850 Family |
Debug-I/F:AUD (RH850/C1x) |
H09 | ◯ | |||||
| Debug-I/F:NEXUS (RH850/P1H-C,P1M-C,P1L-C) |
H10 | ◯ | ◯ | ◯ | ||||
| RH850 Family |
Debug-I/F:NEXUS (RH850/E2M,E2H,E2UH) |
H11 | ◯ | ◯ | ||||
| R-Car S4 (G4MH) |
Debug-I/F:NEXUS (R-Car S4-8,S4N-8,S4-4,S4N-4) |
H12 | ◯ | |||||
| RL78 Family |
Debug-I/F:1 wire Serial (RL78/F23, F24) |
H13 | ◯ | |||||
| RA Family |
Debug-I/F:SWJ(SWD/JTAG) (RA6・RA4・RA2 Series) |
A01 | ◯ | ◯ | ||||
| R-Car Family |
Debug-I/F:SWJ(SWD/JTAG) R-Car S4(Cortex-R52), R-Car V4H(Cortex-R52) |
A01 | ◯ | ◯ | ||||
| NXP Semiconductors |
MPC55xx Family |
Debug-I/F:NEXUS (MPC5554,MPC5567) |
M01 | ◯ | ◯ | |||
| MPC56xx Family |
Debug-I/F:NEXUS (MPC560x) |
M02 | ◯ | ◯ | ||||
| Debug-I/F:NEXUS (MPC5643L) |
M03 | ◯ | ◯ | ◯ | ||||
| Debug-I/F:NEXUS (MPC5634M) |
M04 | ◯ | ◯ | ◯ | ||||
| MPC57xx Family |
Debug-I/F:NEXUS (MPC5744P) |
M05 | ◯ | ◯ | ◯ | |||
| Debug-I/F:NEXUS (MPC5746R,MPC5777M) |
M06 | ◯ | ◯ | |||||
| Debug-I/F:NEXUS (MPC5775K,MPC5774K) |
M07 | ◯ | ◯ | ◯ | ||||
| LPC4300 Series |
Debug-I/F:SWJ(SWD/JTAG) (LPC4357) |
A01 | ◯ | ◯ | ||||
| S32K Series |
Debug-I/F:SWJ(SWD/JTAG) (S32K142,S32K144,S32K3xx) |
A01 | ◯ | ◯ | ||||
| STMicro electronics |
SPC5 Family |
Debug-I/F:NEXUS (SPC57Sxx,SPC574Sxx) |
S01 | ◯ | ||||
| Debug-I/F:NEXUS (SPC58ECxx,SPC584Cxx) |
S02 | ◯ | ||||||
| Debug-I/F:NEXUS (SPC58NExx) |
S03 | ◯ | ◯ | |||||
| Stellar Family |
Debug-I/F:SWJ (SWD/JTAG) (Stellar E Series) |
A01 | ◯ | ◯ | ||||
| Infineon Technologies (The Former "Cypress Semiconductor") |
FR81 Family |
Debug-I/F:MDI (CY91580,CY91780) |
F03 | ◯ | ||||
| Debug-I/F:MDI (CY91520) |
F04 | ◯ | ||||||
| Traveo CY9D560 Series |
Debug-I/F:JTAG (CY9D56X) |
F06 | ◯ | ◯ | ◯ | |||
| Traveo T2G Family |
Debug-I/F:SWJ(SWD/JTAG) (CYT2B9x,CYT2B7x) |
A01 | ◯ | ◯ | ||||
| Infineon Technologies |
AUDO MAX Family |
Debug-I/F:JTAG (TC1782,TC1789) |
I01 | ◯ | ◯ | ◯ | ||
| AURIX-TC2x Family |
Debug-I/F:JTAG (TC21x,TC22x,TC23x,TC24x, TC26x,TC27x,TC29x) |
I02 | ◯ | ◯ | ◯ | |||
| Debug-I/F:DAP (TC21x,TC22x,TC23x,TC24x, TC26x,TC27x,TC29x) |
I03 | ◯ | ◯ | ◯ | ||||
| AURIX-TC3x Family |
Debug-I/F:DAP (TC33x,TC36x,TC37x, TC38x,TC39x) |
I04 | ◯ | ◯ | ||||
| AURIX-TC4x Family |
Debug-I/F:DAP (TC4Dx) |
I05 | ◯ | ◯ | ||||
| TLE987x Series |
Debug-I/F:SWJ(SWD/JTAG) (TLE9877,TLE9879) |
A01 | ◯ | ◯ | ||||
| Toshiba Electronic Devices & Storage |
TX03 Series TXZ4 Series TXZ+4A Series |
Debug-I/F:NBD (M350 Group, M4K Group(1)/(2), TMPM4K Group(1)/(2) TMPM4M Group(1)) |
T01 | ◯ | ||||
Arm® Core Support Probe
| Semiconductor Supplier |
Microcontroller Series/Family Name |
Debug-I/F | Probe Type Name：GT10□△△△ | |||||
|---|---|---|---|---|---|---|---|---|
| △△△ MCU type |
GT102 | GT103 | GT104 | GT106 | GT107 | |||
| Renesas Electronics |
RA Family (RA6・RA4・RA2 Series) |
Debug-I/F:SWJ(SWD/JTAG) | A01 | ◯ | ◯ | |||
| Renesas Electronics |
R-Car Family (R-Car S4(Cortex-R52), R-Car V4H(Cortex-R52)) |
|||||||
| NXP Semiconductors |
LPC4300 Series (LPC4357) |
|||||||
| NXP Semiconductors |
S32K Series (S32K142,S32K144,S32K3xx) |
|||||||
| STMicro electronics |
Stellar Family (Stellar E Series) |
|||||||
| Infineon Technologies |
TLE987x Series (TLE9877,TLE9879) |
|||||||
| Infineon Technologies (The Former "Cypress Semiconductor") |
TRAVEO T2G Family (CYT2B9x,CYT2B7x) |
|||||||
